SW-Motech SW-NSW0000461000-B Universal EVO High Beam Kit Black with Crash Bar Clamps for Lights

The highly concentrated light of the EVO high beams has a particularly wide range. This provides optimal lighting for the rider's view and ensures safety during on- or off-road riding. SW-MOTECH sought out a reliable partner for the development of the new EVO fog lights and relied on the expertise of a long-standing top manufacturer from the automotive sector. Development is focused on meeting the strictest quality standards while also maintaining a compact shape: the EVO high beams are resistant to water and dust, with an IP69 protective class rating. Powerful LEDs provide the best view, while wear-resistant housings ensure long life.

These bike-specific mounts provide optimal positioning of the EVO lights, because they are developed exclusively for each motorcycle model. The sturdy elements made of powder-coated steel are screwed on to existing attachment points. They guarantee secure hold for the EVO lights, even when riding off-road. Please refer to the mounting instructions to determine if headlamps can be mounted standing, hanging and/or sideways on your motorcycle model.

What's in the Set

• 2 × EVO High beams
• 2 × Crash bar clamps for EVO lights
• 1 × Cable harness with safety device
• 1 × Handlebar switch
• Mounting instructions
• Mounting hardware

Specifications

Set Components

Crash Bar Clamps for EVO Lights

• For mounting on crash bars or other vehicle parts with the corresponding diameter
• For SW-MOTECH EVO lights
• Includes rubber inserts for adapting to 22/25.4/26/27 mm and 28 mm.
• Made from fibreglass-reinforced polyamide

Material: Polyamide · Colour: Black · Weight: Approx. 0.2 kg

EVO High Beams

• Trouble- and maintenance-free operation due to almost wear-free LED, considerably reduced energy consumption
• Power output: 12 W each light
• Luminous flux: 800 LM each light
• ECE test mark: ECE R113 Rev.2
• Highly concentrated beam with long-distance range
• Compact size with a diameter of 7.1cm
• Water- and dustproof (safety class: IP69)
• Voltage: 12 V. Cable harness for easy connection to the motorcycle battery included in delivery, no change to motorcycle electric required
• Splash-protected, blue glowing handlebar switch for comfortable operation (Protection class: IPX4)
• Mounting points on all four sides
• Installation on headlight clamps for crash bar (Ø 22, 26, 27, 28 mm) or bike-specific brackets

Material: Aluminium · Finish: Powder coated · Colour: Black · Weight: Approx. 1.3 kg

Please Note: Note that due to the curvature of the reflector the "TOP" mark must always be at the top. Light clamps for crash bar and bike-specific mounts are available separately. Please observe the legal regulations applicable in your country for the operation and installation of high beams

Required for Fitting: Crash bar clamps or bike-specific light mount

Please Note

• Only mountable with SW-MOTECH logo up due to reflector curvature
• Please observe the legal regulations applicable in your country for the operation and installation of high beams.
